170*65mm Outside Dimension D*H Toroidal Transformer for Testing Equipment

170*65mm Outside Dimension D*H Toroidal Transformer for Testing Equipment

    • 170*65mm Outside Dimension D*H Toroidal Transformer for Testing Equipment
    • 170*65mm Outside Dimension D*H Toroidal Transformer for Testing Equipment
    • 170*65mm Outside Dimension D*H Toroidal Transformer for Testing Equipment
    • 170*65mm Outside Dimension D*H Toroidal Transformer for Testing Equipment
    • 170*65mm Outside Dimension D*H Toroidal Transformer for Testing Equipment
    • 170*65mm Outside Dimension D*H Toroidal Transformer for Testing Equipment
    • 170*65mm Outside Dimension D*H Toroidal Transformer for Testing Equipment

    Détails sur le produit:

    Place of Origin: CHINA
    Nom de marque: IKP
    Certification: CE/UL/REACH/ROHS
    Numéro de modèle: Transformateur toroïdal

    Conditions de paiement et expédition:

    Quantité de commande min: 1000
    Prix: 3.00-20.00
    Détails d'emballage: Carton
    Délai de livraison: 10-15 jours
    Conditions de paiement: L / C, T / T
    Capacité d'approvisionnement: 100 000 / semaine
    Contactez
    Description de produit détaillée

    Specifications:

    • Power range:100VA to 1000VA

    • Input / Output: Customized

    • Insulation Class: UL class B, F, H, N (optional)

    • Isolation: 4KV (Hi-pot)

    • Easy to change diameter and height of the core

    • Customized specifications are welcome

    Rated Power

    (VA)

    Outside Dimension

    D*H(mm)

    Weight

    (kg)

    Temp. Rise

    (℃)

    		Approval
    100 95*45 1.24 51 UL/CE/RoHS/CQC
    300 125*56 2.95 53 UL/CE/RoHS/CQC
    500 140*65 4.20 55 UL/CE/RoHS/CQC
    600 146*71 5.20 56 UL/CE/RoHS/CQC
    800 170*65 6.30 57 UL/CE/RoHS/CQC
    1000 170*75 7.20 58 UL/CE/RoHS/CQC



    ◆We can design and manufacture customized part with specific requirement



    170*65mm Outside Dimension D*H Toroidal Transformer for Testing Equipment◆We can design and manufacture customized part with specific requirement◆We can design and manufacture customized part with specific requirement



    170*65mm Outside Dimension D*H Toroidal Transformer for Testing Equipment170*65mm Outside Dimension D*H Toroidal Transformer for Testing Equipment170*65mm Outside Dimension D*H Toroidal Transformer for Testing Equipment170*65mm Outside Dimension D*H Toroidal Transformer for Testing Equipment
